Rel Acoustics T9x

Περιγραφή

Rel Acoustics T9x

Το T9x όπως κάθε κορυφαίο Rel έχει μια αποστολή, να δώσει περισσότερο χαμηλό περισσότερα δυναμικά περισσότερη ενέργεια είτε χρησιμοποιείται σε σύστημα οικιακού κινηματογράφου είτε σε δικάναλο hi end σύστημα. Το T9x τα κάνει όλα αυτά με ευκολία. Το T9x επανασχεδιάστηκε και έτσι μεγάλωσε η καμπίνα του είναι η απάντηση στον πραγματικό κόσμο. Το T9x έχει ένα 10 ιντσών long throw γούφερ με κώνο από FibreAlloy™ και ένα παθητικό ακτινοβολητή επίσης 10 ιντσών long throw από FibreAlloy™. Είναι εξοπλισμένο με ποιοτικό ενισχυτή 300 watt τάξης Α/Β με πολύ μεγάλα αποθέματα ισχύος ενώ διαθέτει όλες τις ρυθμίσεις και συνδέσεις όπως η High Level είσοδος που χρησιμοποιείται σε hi end δικάναλα συστήματα αλλά και LFE είσοδος με δικό της level control για συστήματα οικιακού κινηματογράφου. Επιπλέον το T9x διαθέτει standby κύκλωμα το οποίο ενεργοποιείται ακόμα και σε εξαιρετικά χαμηλές εντάσεις.

• Reimagined, Then Reengineered
  A COMPLETELY REDESIGNED FLAGSHIP
  Many don’t realize the intense linkage between performance and design here at REL. Performance is everything to us and so it drives physical design revisions. Our engineers, recognizing the need for greater acoustic volume to achieve the goals of greater fluidity and power, turn to the designer who works dimensions to fool the eye into seeing a smaller, more compact footprint even though cabinet volume increases. Using gently rounded corner radii that allows the eye to flow over and see less visual mass. The result is both modern and familiar with no unnecessary adornment.
• Outsized Performance
  INNOVATIVE ALLOY/FIBRE BASS ENGINES
  To achieve higher output with better control requires a complete overhaul of the suspension components. Much like the suspension on a sports car, these items are responsible for the tuning and feel of our designs. By increasing the cabinet volume, efficiency is improved yielding higher output for no more amplifier power. Less back pressure inside the cabinet means we can tune for a stiffer, better controlled driver suspension. We retained the best aspects of our previous design, such as the aluminum center cap responsible for stiffening the lightweight 10” (250mm) cone while adding almost no mass. The updated combination produces considerably better attack and dynamics with greater transparency.
• Tried and True Amplifiers
  THE BRAINS BEHIND THE BRAWN
  We have retained our signature Class A/B amplifiers used in every generation of Serie T since 2006. Reliability is the key to happy ownership and with some 200,000 and counting of this range leading long happy lives, Serie T/x owners can feel certain of REL’s standard setting reliability. The powerful 300 watt mosfet amplifier used in the T/9x remains an icon with huge reserves of current, massive power supplies but small upgrades are found everywhere. New driver mosfets that open up performance and transparency and new methods for securing the toroidal transformers mean better performance and superior strength.
• REL’s legendary High Level Input connection and fast filters are a significant part of the REL story. Connecting via the speaker outputs of your amplifier without drawing any power from it may seem like magic, but the real magic lies in the way the sound takes on a natural character. Unique tuning and special limiters means the T/x range sounds fresher, faster and more dynamic than before.
• Standby Mode switch is only included on 220V units.
• Specifications
  TYPE
  Front-firing active driver, down-firing passive
• ACTIVE DRIVER SIZE & MATERIAL
  10 in. (250mm) long-throw, FibreAlloy™ cone, inverted alloy centre cap, steel chassis
• PASSIVE RADIATOR SIZE & MATERIAL
  10 in. (250mm) long-throw, FibreAlloy™ cone, inverted alloy centre cap, steel chassis
• LOW FREQUENCY EXTENSION
  -6dB at 27 Hz
• INPUT CONNECTORS
  High Level Neutrik Speakon, Low Level (1) RCA, (1) LFE RCA
• OUTPUT CONNECTORS
  N/A
• POWER OUTPUT
  300 watts (RMS)
• AMPLIFIER TYPE
  Class A/B
• WIRELESS CAPABILITY
  REL Arrow (sold separately)
• DUAL PARAMETRIC FILTER
  N/A
• Protection System
  FULLY ELECTRONIC SET SAFE
  Yes
• D.C. FAULT
  Yes
• OUTPUT SHORT
  Yes
• MAINS INPUT VOLTAGE
  220-240 volts, 110-120 volts for certain markets
• FUSES
  3.15 Amp semi delay 230 volts operation, 6.3 Amp semi delay 115 volts operation
• Dimensions
  W X H X D
  14.5 x 13.4 x 15.5 in., (370 x 340 x 393 mm)
• NET WEIGHT
  45.5 lbs. (20.6 kg)
• FINISH
  Piano Black Lacquer, Gloss White Lacquer 5 coats
• Supplied Accessories
  MAINS LEAD
  Yes
• NEUTRIK SPEAKON
  Yes (10 Meters Nominal)
• INTERCONNECT
  USERS MANUAL
  Yes
