EverSolo AMP-F2

Περιγραφή

EverSolo AMP-F2

EverSolo AMP-F2

Ο EverSolo AMP-F2, που αναπτύχθηκε σε συνεργασία με την ομάδα Starke Sound, είναι ένας ενισχυτής τάξης D που βασίζεται στην ενσωμάτωση της καινοτόμου μονάδας NS600 του τελευταίου. Ως αποτέλεσμα, προσφέρει υψηλή απόθεμα ισχύος, εξαιρετική δυναμική και ήχο υψηλής ακρίβειας. Το ολοκαίνουργιο τροφοδοτικό λειτουργίας διακόπτη SAPS παρέχει στο κύκλωμα ήχου ένα καθαρό ηλεκτρικό σήμα, διασφαλίζοντας πολύ χαμηλά επίπεδα θορύβου και παραμόρφωσης. Bridgeable, το AMP-F2 είναι ένα ευέλικτο μοντέλο που μπορεί να χρησιμοποιηθεί σε στερεοφωνικό ή μονοφωνικό. Βασισμένο στη μονάδα ενισχυτή NS600 Class D της Starke Sound, το EverSolo AMP-F2 είναι ικανό να προσφέρει σημαντική ισχύ, έως και 2x250W RMS στα 4 Ohm (1% THD). Όταν ο ενισχυτής χρησιμοποιείται γεφυρωμένος (BTL), δηλαδή μονοφωνικός, η ισχύς του αυξάνεται στα 450 W RMS στα 2 Ohm (1% THD). Αυτή η ικανότητα υποστήριξης σύνθετων αντιστάσεων πολύ χαμηλού φορτίου εξασφαλίζει επαρκή ισχύ ακόμη και σε διαμορφώσεις που χρησιμοποιούν ιδιαίτερα απαιτητικά ηχεία.

EverSolo AMP-F2

The EverSolo AMP-F2, developed in collaboration with the Starke Sound team, is a Class D amplifier based on the integration of the latter’s innovative NS600 module. As a result, it offers high power reserve, excellent dynamics and high-precision sound. The brand new SAPS switch mode power supply provides the audio circuit with a clean electrical signal, ensuring very low noise and distortion levels. Bridgeable, the AMP-F2 is a versatile model that can be used in stereo or mono. Based on the NS600 Class D amplifier module from Starke Sound, the EverSolo AMP-F2 is capable of delivering significant power, up to 2x250W RMS at 4 Ohm (1% THD). When the amplifier is used bridged (BTL), i.e. mono, its power increases to 450W RMS at 2 Ohm (1% THD). This ability to support very low load impedances ensures sufficient power even in configurations using particularly demanding speakers.

EverSolo AMP-F2: A generously dimensioned power supply
Featuring a high-performance 600W power supply, the EverSolo AMP-F2 stands out for its exceptional power management capabilities. With low levels of ripple and EMI (Electromagnetic Interference), this power supply ensures an output that is not only stable and powerful, but also remarkably clean and reliable. This is crucial for devices that are sensitive to power fluctuations, where precision and consistency are essential. Its intelligent design also contributes to greater energy efficiency, reducing the environmental footprint while ensuring optimum performance.

The EverSolo AMP-F2’s energy efficiency doesn’t stop at low standby power consumption. This amplifier is designed to maximise energy efficiency at all levels of use. In active mode, it intelligently adjusts its power consumption according to the signal being processed, avoiding electricity wastage while delivering optimum audio performance. This dynamic power management not only helps to reduce energy costs for the user, but also plays a significant role in reducing the device’s ecological footprint.
What’s more, the integration of the latest-generation electronic components in the EverSolo AMP-F2 enables it to achieve an exceptional level of sonic precision, while maintaining a minimal energy footprint.
Finally, compliance with European Union ErP standards is a further guarantee of the quality and environmental responsibility of the EverSolo AMP-F2. These standards, which are among the strictest in the world, ensure that the device has been designed and tested to meet today’s environmental requirements.

The design of the EverSolo AMP-F2 amplifier is enhanced by its modern, robust aluminium chassis, a choice that combines aesthetics and functionality. As well as its sleek, contemporary appearance, the aluminium chassis plays a crucial role in the protection and performance of the device. It offers resistance to impact and corrosion, guaranteeing a long service life. What’s more, this material is renowned for its ability to dissipate heat efficiently, helping to maintain an optimum temperature within the amplifier, which is essential for preserving the quality of the internal components over the long term. The chassis also acts as an effective shield, significantly limiting the impact of external electromagnetic interference on the AMP-F2’s sensitive circuitry. This shielding function is particularly important in environments rich in electronic equipment, where interference can affect signal quality and overall performance. In short, the aluminium chassis of the EverSolo AMP-F2 is more than just an aesthetic feature; it is a key component in ensuring the durability, reliability and high performance of the device.

EverSolo AMP-F2 Specifications
Product type Amplifier
Amplification type Class D
Output power 2x250W RMS @ 4Ω (1% THD)
2x145W @ 8Ω (1% THD)
Output power (BTL) 280W RMS @ 4Ω (1% THD)
450W RMS @ 2Ω (1% THD)
Inputs Single-ended RCA
Balanced XLR
Outputs Speaker terminals (beryllium copper)
Gain 21.5dB
Frequency response 10Hz – 20kHz (-1dB)
Max. output current per channel 16.5A
33A (BTL)
THD 0.003% @ 10W, 1kHz
SNR > 110dBA @ 4Ω, 260W
Input impedance RCA : 11kΩ
XLR : 22kΩ
Input sensitivity 2.7V
Output impedance 0.136Ω (5Hz à 100kHz)
Minimum load impedance 0.8Ω
Damping factor 100
Balanced circuit
Trigger 5-12V Input and output
General
Supply voltage 115VAC – 230VAC (switchable)
Heat 65BTU / hour
Consumption Standby: ≤ 0.5W
Idle: ≤ 14W
Max: 900W
Dimensions 270 x 228 x 80mm
Housing material Aluminum
Weight 3.65kg
Color Black
